Flexible LED screen for Indoor Use

Flexible LED screen for interiors are designed for curved and non-standard surfaces: columns, waves, arches and custom forms with sharp image quality and a lightweight structure.

Description

Flexible LED screen for Indoor Use

Flexible LED screen for interiors are designed for curved and non-standard surfaces: columns, waves, arches and custom forms with sharp image quality and a lightweight structure.

Project Configuration

The final configuration is selected according to the site geometry, the viewing distance, service access and operating conditions. Tegroled adapts the structure, mounting scheme and control setup to the real task of the project.

Calculation

The final budget and technical package are prepared individually after the project parameters are agreed with the manager or through the calculator.

Specifications

FieldValue
Pixel pitchP1.5 / P1.8 / P2 / P2.5 / P3 (indoor)
Brightness800-1 500 cd/m²
Module size240x120 mm / 320x160 mm (flex modules)
Cabinet sizemodular assembly for the project radius and shape
Refresh rate1920-3840 Hz
Viewing distancefrom 1.5 m
Average power180-280 W/m²
Peak power450-700 W/m²
Protection classIP31-IP43 (indoor)
Service accessfront / rear service
Lifetimeup to 100 000 h
Warranty12-24 months
NoteFlexible modular architecture for curved and non-standard surfaces. Final configuration depends on project geometry.
